The T3 SNAP PLUG™ and SNAP PLUG Tool is designed to simplify the process of terminating RJ45 modular plugs.

It is a time-consuming process to assemble traditional RJ45 modular plugs, and the most difficult part would be putting the wire into the conductor in correct order. The thicker the conductor is, the more difficult the job is going to be.

The T3 SNAP PLUG™ enables the conductors to pass through the connector itself, making it a lot easier to verify wiring order before crimp, reducing possible errors and waste of materials, save time and effort on terminating RJ45 connectors.
Use the SNAP PLUG TOOL to crimp and trim in a single step, making professional wire termination fast and easy.

These shielded snap plugs come with copper fabric strips for bonding the shielded ethernet cable. The copper fabric strips are on removable plastic sheets for easy handling. This bonding allows the connection hardware to drain off effectively those excess electromagnetic interference (EMI/RFI) and ESD (electrostatic discharge).

The steps for using the copper fabric strip are:

• Prepare the ethernet cable like normal
• Remove the cable shield of the ethernet cable
• Fold back and wrap the drain wire around the cable jacket
• Bond the copper fabric strip to the cable jacket while securing the drain wire under it
• Terminate the RJ45 plug like normal

Specifications:

• Shielded RJ45
• Pack of 50pcs
• Max conductor size: 1.2mm / 0.047"
• Solid or stranded cable: 23 AWG
• Cat6a STP 1pc, 3 prongs
• 50u fully gold plated RJ45 pin contacts
• Internal ground
• Copper fabric strip size: 15mm x 32mm
• Meets ANSI/TIA specifications
• Compliant with POE and POH standards
